How to Properly Jack Up a Model 3/Model S/Model X/Model Y,so you dont damage the ~30,000+ battery Warning: Always chock the wheels when jacking. Do not start work on the underside of the vehicle until safety stands have been positioned under the body reinforced pads. Never get under a vehicle that is only supported by a jack. Follow the steps below to lift Model 3/S/X/Y. Ensure that any non-Tesla repair facility is aware of these lifting points. 1.Position Model 3/S/X/Y centrally between the lift posts. 2.Position the lift arm pads under the designated body lift points at the locations shown. Warning: DO NOT position the lift arm pads under the Battery or side rails, as shown in red. 3.Adjust the height and position of the lift arm pads to ensure that they are correctly located. 4.With assistance, raise the lift to the desired height, ensuring the lift arm pads remain in their correct positions. 5. Engage any lift safety locks. Follow the lift manufacturers instructions. Warning: Never raise Model 3 when the charge cable is connected, even if charging is not in progress. Warning: Do not work on an incorrectly supported vehicle. Doing so can cause serious damage, bodily injury, or death. Caution: DO NOT lift from under the Battery or side rails. Place the lift arm pads under the designated body lift points only. The locations shown are the only approved lifting points for Model 3. Lifting at any other points can cause damage. Damage caused by incorrectly lifting Model 3/S/X/Y is not covered by the warranty What is the jacking point? The jacking points are located at 4 locations around a car (see above), theyre locations that youre safe to lift with a hydraulic jack or two post lift. The difference to a normal car is that to one side of the jacking point there is a 30,000 battery which the owner of the vehicle wont want you damaging and nor will your insurance company. You should always avoid touching anywhere BUT the jacking point Gift: With a Portable EVA Tool Case !
