Basic product information: •• Operating manual Languages: Dutch, English, French, German, Polish, Portuguese, Spanish •• Primary colours: Black •• Additional colours: Red •• Depth unit: 40 mm •• Height unit: 190 mm • • Width Unit: 100 mm •• Weight Unit: 300 g •• Material: Abs • Physical properties: •• Cable length: 0.75 M •• Display height: 36 mm •• Display width: 62 mm •• Display type: LCD • • Backlight: Yes •• Maximum digits Display: 1999 • Electrical data: •• Ac Current: Basic accuracy: ± (1.5% Rdg + 3 digits), ± (2.0% Rdg + 3 digits) for 200 Ma range, ± (2.5% Rdg + 5 digits) for 15 A range Overload protection: 500 Ma / 600 V, 15 A / 600 V fuse Frequency range: 40-500 Hz •• AC voltage: Basic accuracy: ± (0.8% Rdg + 3 digits), ± (1.2% Rdg + 3 digits) for 600 V range Input impedance: 1 megohm for 2 V range, 10 megohms for other ranges Frequency range: 40-500 Hz Maximum input: 600V DC or AC Rms Test A: = or >,= •• Audible continuity measurement: Yes •• Audible continuity: Built-in buzzer sounds if the resistance is less than 50 ohms Test voltage: Approx. 3 V •• Automatic polarity indication: Yes •• Capacity: Basic accuracy: ± (2.5% Rdg + 10 digits) for 2000 Pf range, ± (2.5% Rdg + 5 digits) for 20Nf to 20 ΜF range, ± (5.0% Rdg + 10 digits) for 200 ΜF range Overload protection: 500 Ma / 600 V fuse •• DC current: Basic accuracy: ± (1.2% Rdg + 2 digits), ± (1.5% Rdg + 2 digits) for 200 Ma range, ± (2.0% Rdg + 3 digits) for 15 A range Overload protection: 500 Ma / 600 V, 15 A / 600 V fuse •• DC voltage: Basic accuracy: ± (0.5% Rdg + 2 digits), ±(0.8% Rdg + 2 digits) for the 600 V range Input impedance: 10 Mohm Maximum input: 600 V Overload protection: 600 V DC or AC Rms •• Diod test: Yes •• Diod test specifications: Test voltage: Approx. 3 V (reverse DC voltage) •• Frequency: Basic accuracy: ± (2.0% Rdg + 5 digits) Overload protection: 600 Vdc or AC Rms Sensitivity: Sine wave 0.5 V Rms •• Fuse type: F 0.50 A / 600 Vac / 500 Vdc, 5 x 20 mm, Breaking capacity 1 ka, F 15 A / 1000 Vac / 1000 Vdc, 6 x 32 mm, Breaking capacity 10 ka •• Indication out of range: Yes •• Temperature measurement Celsius Specifications: -50 - 150 °C / 150 - 800 °C Basic accuracy: ± (3 °C + 3 digits) For -50 - 150 °C range ± (3% + 3 digits) For range 150 - 800 °C Overload protection: 500 Ma / 600 V fuse Nicr-Nisi sensor K Thermocouple probe: Included •• Transistor test: No •• AC current measurements: 15 A, 2 Ma, 20 Ma, 200 ΜA, 200 Ma •• AC voltage measurements: 0-2 V, 20 V, 200 V, 600 V •• Capacity measurements: 2 ΜF, 20 Nf, 200 ΜF, 200 Nf, 2000 Pf •• DC current measurements: 0.2 Ma, 15 A, 2 Ma, 20 Ma, 200 ΜA, 200 Ma •• DC voltage measurements: 0-200 Mv, , 20 V, 200 V, 600 V •• Frequency measurements: 20 Khz •• Resistance Dimensions: 0-200 Ohm, 2 Kohm, 2 Megohm, 20 Kohm, 20 Megohm, 200 Kohm, 200 Megohm •• Resistance Specifications: Basic Accuracy: ± (1.0% Rdg + 3 digits) for 200 ohm range, ± (1.0% Rdg + 2 digits) for 2 Kohm to 2 Mohm range, ± (1.5% Rdg + 3 digits) for 20 Mohm range, ± (5.0% Rdg + 5 digits) for 200 Mohm range Overload protection: 600 Vdc or AC Rms • Technical data: •• Safety Rating: Cat Iii / 600 V, Cat Iv / 300 V •• Voltage Tester Type: AC / DC •• Auto Shut-Off Function: Yes •• Contamination Rate: 2 •• Data Retention Function: No • Environmental Data: •• IP Rating: Ipx0 •• Place of Use: Indoor Only •• Operating Temperature °C: 0-40 °C •• Operating Temperature °F: 32-104 °F •• Storage Temperature °C: -20-60 °C •• Storage Temperature °F: -4-140 °F •• Maximum Storage Humidity: < 90% •• Maximum Operating Humidity: < 80% • Operating Characteristics.< br><br>
